Precision compounding at industrial scale
The JP-TE Series co-rotating twin-screw extruder is the platform of choice for demanding compounding and reactive extrusion applications. Its fully modular barrel and screw element design enables rapid reconfiguration for different formulations — from filled masterbatches to highly devolatilised engineering compounds.
The high-torque distribution gearbox (T/A³ = 14 Nm/cm³) sustains screw speeds to 600 rpm on the 52mm variant, enabling high-throughput processing of shear-sensitive materials without thermal degradation.
Key Features
| Screw Diameter | 52 mm |
| L/D Ratio | 40:1 |
| Max Throughput | 120 kg/hr |
| Max Screw Speed | 600 rpm |
| Drive Motor Power | 75 kW |
| Number of Barrel Sections | 10 |
| Max Process Temperature | 400°C |
| Max Torque per Shaft | 380 Nm |
| Feeder Positions Available | Side feeder port × 2 |
| Overall Dimensions (L×W×H) | 4,800 × 800 × 1,600 mm |
| Screw Diameter | 67 mm |
| L/D Ratio | 40:1 |
| Max Throughput | 200 kg/hr |
| Max Screw Speed | 500 rpm |
| Drive Motor Power | 132 kW |
| Number of Barrel Sections | 10 |
| Max Process Temperature | 400°C |
| Max Torque per Shaft | 820 Nm |
| Feeder Positions Available | Side feeder port × 3 |
| Overall Dimensions (L×W×H) | 5,600 × 950 × 1,700 mm |
| Screw Diameter | 75 mm |
| L/D Ratio | 52:1 |
| Max Throughput | 280 kg/hr |
| Max Screw Speed | 500 rpm |
| Drive Motor Power | 200 kW |
| Number of Barrel Sections | 13 |
| Max Process Temperature | 400°C |
| Max Torque per Shaft | 1,200 Nm |
| Feeder Positions Available | Side feeder port × 4 |
| Overall Dimensions (L×W×H) | 7,200 × 1,050 × 1,800 mm |
| Screw Diameter | 95 mm |
| L/D Ratio | 52:1 |
| Max Throughput | 350 kg/hr |
| Max Screw Speed | 400 rpm |
| Drive Motor Power | 315 kW |
| Number of Barrel Sections | 13 |
| Max Process Temperature | 400°C |
| Max Torque per Shaft | 2,400 Nm |
| Feeder Positions Available | Side feeder port × 4 |
| Overall Dimensions (L×W×H) | 8,800 × 1,250 × 2,000 mm |
Colour, additive, and filler masterbatches for PE, PP, PET, and engineering resin carriers.
Glass fibre, carbon fibre, mineral-filled, and flame-retardant compound production.
Removal of residual monomers, solvents, and moisture from polymer melts via vented processing.
In-situ grafting, chain extension, and reactive blending for performance polymer development.
Miscible and immiscible blend production with compatibilisers for TPE, TPV, and alloy formulations.
