Stable, tension-controlled cable winding for wire and cable production lines
The JP-AT Series A-type Take-Up is a compact, floor-standing winding unit designed for controlled cable winding at the end of wire and cable extrusion or processing lines. The A-frame structure provides a low centre of gravity and stable bobbin support — critical for maintaining consistent layer winding and preventing reel wobble at higher line speeds.
Three models address progressively larger bobbin sizes. The JP-AT 400 is the standard production unit for smaller cables and tighter reel formats common in residential wire manufacturing. The JP-AT 500 adds higher torque capacity and a wider bobbin width range for medium-diameter cables. The JP-AT 630 is the high-capacity model with a variable-speed dancer arm tension control system and automatic traverse mechanism — suited for premium cable winding where layer consistency directly affects downstream drum packing efficiency.
Key Features
Three models covering standard to high-capacity bobbin sizes. All share the same traverse and tension control platform.
| Max Bobbin Diameter | 400 mm |
| Max Bobbin Width | 250 mm |
| Max Line Speed | 0–120 m/min |
| Tension Tolerance | ±0.5% |
| Drive Motor Power | 1.5 kW |
| Drive Type | Variable frequency drive |
| Traverse Type | Mechanical cam traverse |
| Machine Weight | ~120 kg |
| Overall Dimensions (L×W×H) | 900 × 600 × 1100 mm |
| Max Bobbin Diameter | 500 mm |
| Max Bobbin Width | 350 mm |
| Max Line Speed | 0–160 m/min |
| Tension Tolerance | ±0.5% |
| Drive Motor Power | 2.2 kW |
| Drive Type | Variable frequency drive with dancer arm |
| Traverse Type | Motorised lead-screw traverse |
| Machine Weight | ~180 kg |
| Overall Dimensions (L×W×H) | 1050 × 700 × 1250 mm |
| Max Bobbin Diameter | 630 mm |
| Max Bobbin Width | 500 mm |
| Max Line Speed | 0–200 m/min |
| Tension Tolerance | ±0.5% |
| Drive Motor Power | 3.7 kW |
| Drive Type | Servo-controlled VFD with closed-loop dancer tension |
| Traverse Type | Servo motorised traverse with programmable pitch |
| Machine Weight | ~280 kg |
| Overall Dimensions (L×W×H) | 1300 × 850 × 1450 mm |
Winding single-core and twin-core PVC-insulated house wire onto standard bobbins — consistent layer winding and tension control for neat, transport-safe reel packs.
Precise layer winding for multi-core control cables — automatic traverse ensures uniform pitch across the full bobbin width for tight, stable drum packing.
Low-tension winding for flexible rubber cables where excessive tension would deform soft insulation — dancer arm control maintains consistent force regardless of bobbin build-up.
High-speed winding of coaxial and LAN cables — servo traverse maintains precise pitch on precision-wound reels where layer accuracy affects insertion-loss performance.
