High-speed accurate cable rewinding and coil management for wire and cable lines
The JP-RW Series Rewinder is a standalone cable rewinding unit designed for transferring cable from production reels to smaller customer reels, or for repackaging cable from bulk drums to retail coils. The motorised winding head with integral traverse mechanism ensures flat, even layering on every coil — critical for preventing tangling during customer uncoiling and maintaining conductor quality in premium cable products.
Three models scale for different line speed and reel size requirements. The JP-RW 200 handles smaller domestic wire sizes up to 200 mm reel diameter — compact and suited to small-batch retail coil production. The JP-RW 400 adds a wider reel range and speed control for medium-throughput rewinding operations. The JP-RW 630 is the high-speed production model with dancer arm tension control, servo traverse, and automatic length counter — matching reel footage to customer order requirements without manual measurement.
Key Features
Three models scaled for small coil retail operations through to high-speed bulk rewinding. All feature automatic traverse and digital footage counting.
| Max Reel Diameter | 200 mm |
| Max Rewinding Speed | 0–150 m/min |
| Cable Diameter Range | 0.5–6 mm |
| Drive Motor Power | 0.75 kW |
| Drive Type | Variable frequency drive |
| Traverse Type | Mechanical cam traverse |
| Footage Counter | Digital metre counter |
| Machine Weight | ~55 kg |
| Overall Dimensions (L×W×H) | 700 × 500 × 1000 mm |
| Max Reel Diameter | 400 mm |
| Max Rewinding Speed | 0–280 m/min |
| Cable Diameter Range | 0.5–12 mm |
| Drive Motor Power | 1.5 kW |
| Drive Type | Variable frequency drive with dancer arm |
| Traverse Type | Motorised lead-screw traverse |
| Footage Counter | Digital metre counter with auto-stop |
| Machine Weight | ~110 kg |
| Overall Dimensions (L×W×H) | 900 × 650 × 1200 mm |
| Max Reel Diameter | 630 mm |
| Max Rewinding Speed | 0–400 m/min |
| Cable Diameter Range | 0.5–20 mm |
| Drive Motor Power | 3.7 kW |
| Drive Type | Servo-controlled VFD with closed-loop dancer tension |
| Traverse Type | Servo motorised traverse with programmable pitch |
| Footage Counter | Digital metre counter with programmable auto-stop and batch reset |
| Machine Weight | ~220 kg |
| Overall Dimensions (L×W×H) | 1200 × 800 × 1450 mm |
Rewinding bulk production cable from large reels into standard retail coils of preset lengths — accurate footage counting and auto-stop ensures every coil meets customer length specifications.
Precision cut-to-length rewinding for industrial cable supply — programmable metre stop and batch counter enables high-volume order fulfilment with minimal operator intervention.
Slow-speed rewinding for visual inspection, spark testing, and diameter gauging — controlled tension during inspection prevents conductor damage while allowing full-length cable examination.
Joining short reel ends from the production line onto single customer reels — reduces scrap and provides better reel utilisation for high-value specialty cable products.
